Our company’s Integrated Tiltmeter, a fixed MEMS-based tilt sensor, uses high-precision imported acceleration chips, 4G tech and intelligent chips. It measures structural tilt/deformation (bridges, buildings, railways) and suits hidden parts, enabling long-term automated testing.
|
Place of Origin: |
Changsha，China |
|
Brand Name: |
Kingmach |
|
Model Number: |
JMQJ-7315RTU |
|
Certification: |
GB/T 38204-2019、SL 362-2006、DL/T 2163-2022 |
|
Minimum Order Quantity: |
1 Piece |
|
Price: |
Negotiable |
|
Packaging Details: |
Cartons or wooden cases. Customized packaging solutions are also available. |
|
Delivery Time: |
Shipped within 30 days after full payment receipt. |
|
Payment Terms: |
T/T in advance. |
Introduction:
The Integrated Tiltmeter is an integrated tilt sensor developed and produced by our company using micro-electromechanical systems. The sensor uses high-precision imported acceleration integrated chips as sensitive elements and is combined with 4G wireless communication technology and other intelligent chip technologies to produce a fixed-type sensor for measuring tilt angles. It is used to observe the tilt angle changes and deformations of bridges, buildings, railways and other structures relative to the horizontal plane. It is suitable for conventional measurement methods and the deformation of hidden parts that are difficult to observe. It can be used for long-term testing in conjunction with automated systems.
Product Features：
· Based on 3D-MEMS acceleration sensor technology and differential measurement principle design, it effectively reduces the impact of temperature drift and power supply ripple.
· Fully sealed, waterproof and dustproof design, suitable for various construction environments.
· With 4G wireless communication, it is convenient for users to apply and configure flexibly.
· It can be conveniently connected to our company's automated test system, making it easy to realize remote unattended automatic measurement.
|
Parameter Item |
Details |
|
Measurement Range |
±30° (Dual-axis) ±15° (Dual-axis) |
|
Resolution |
0.001 |
|
Accuracy |
±0.05% FS |
|
Power Supply Battery |
3.6V/38AH |
|
Operating Current |
≤150mA during measurement, ≤60mA during standby, ≤5μA during sleep |
|
Output Signal |
Wireless 4G Digital Signal Output |
|
Operating Temperature Range |
-10℃ ~ 55℃ |
|
Temperature Drift |
±0.1% FS/℃ |
|
Long-term Stability |
±0.1% FS/Year |
|
Waterproof Grade |
Ip65 |
