Micro Range Hydrostatic Level Sensor JMQJ-62XXADT

The Micro Range Hydrostatic Level Sensor is widely used for precision measurement in various engineering scenarios such as dam settlement, bridge deflection, slope stability, and building settlement across the engineering field.

Download

Free consultation

General product information

Place of Origin:	Changsha，China
Brand Name:	Kingmach
Model Number:	JMQJ-62XXADT
Certification:	ISO9001、ISO14001、ISO45001

Product Business Terms

Minimum Order Quantity:	1 Piece
Price:	Negotiable
Packaging Details:	Cartons or wooden cases. Customized packaging solutions are also available.
Delivery Time:	Shipped within 30 days after full payment receipt.
Payment Terms:	T/T in advance.

Description

The Tilt Hydrostatic Leveling Sensor is a tilt-based settlement monitoring sensor launched by our company. Compared to traditional settlement monitoring sensors, this product utilizes advanced components and industrial design, featuring a compact size, fast response speed, and good long-term stability. Multiple sensors are connected via water pipes to form a settlement testing system, which is widely used for precise measurement of vertical displacement changes in structures such as road linear settlement and profile settlement, dam linear settlement, and bridge deflection.

When paired with our data acquisition system (bus modules and software), it enables unmanned monitoring or remote data collection.

Applications

· Monitoring of various subgrade settlements

· Dam deformation monitoring

· Tunnel settlement monitoring

· Large building deformation monitoring

· Bridge deflection monitoring

specifications

Item	JMQJ-6205d0 / JMQJ-6210d0
Standard Range	50mm / 100mm
Resolution	0.01mm
Accuracy	0.5% F.S
Power Supply Voltage	DC 9V~24V
Power Consumption	<0.4W
Output Signal	RS485 digital signal
Temperature Drift	±0.001 MM/℃ (Note: Suspected unit error, typically mm/°C)
Long-term Stability	±0.1% FS/year
Operating Temperature	-40℃~80℃
Mechanical Dimensions	50mm Range: 230mm120mm140mm 100mm Range: 240mm120mm190mm
Weight	Approx. 4.5kg
Ingress Protection (IP) Rating	IP68
