DTU JMTX-2023DTU

DTU JMTX-2023DTU

The DTU product uses wireless cellular networks as the medium to complete remote data collection and transmission, enabling remote management and monitoring in the industrial field.

Download

Free consultation

General product information

Place of Origin:	Changsha，China
Brand Name:	Kingmach
Model Number:	JMTX-2023DTU
Certification:	ISO9001、ISO14001、ISO45001

Product Business Terms

Minimum Order Quantity:	1 Piece
Price:	Negotiable
Packaging Details:	Cartons or wooden cases. Customized packaging solutions are also available.
Delivery Time:	Shipped within 30 days after full payment receipt.
Payment Terms:	T/T in advance.

Description

Product Features:

| All-network 4G CAT1 DTU

| 9~24V wide-voltage power supply

| Hardware watchdog protection

| Supports simultaneous use of both RS232 and RS485 interfaces

| Supports simultaneous use of 4-channel TCP interface socket transparent transmission

| Supports offline caching (customization required)

| Hardware reliability: Interface reverse connection protection

| Supports remote upgrade

| Supports serial port and network AT commands

| Supports base station positioning

| Reserves two channels of IO function ports

Applications

The JMTX-2023DTU product uses wireless cellular networks as the medium to complete remote data collection and transmission, enabling remote management and monitoring in the industrial field.

The JMTX-2023DTU supports simultaneous use of RS232 and RS485 ports, and can support connection to TCP servers of up to 4 clients at the same time. Equipped with the IoT terminal management platform developed by our company, the DTU supports functions such as remote parameter configuration, remote debugging, remote upgrade, and remote upgrade of devices.

specifications

Specification
Dimensions	103mm×64.2mm×23.5mm
Operating Temperature	-30℃~+75℃
Operating Humidity	5%~95%
Supply Voltage	9V~24V DC Power Supply
Power Consumption	40mA@12V
Interface
Power Interface	Plug-in DC Port
Indicators	WORK Operation Status Indicator:Always on: Not connected to base stationSlow flash: Connected to base station (cycle 2s)Flash: Serial port data transceiver (cycle 200ms)NET Data Indicator:Fast flash: Server disconnected (cycle 400ms)Always on: Server connected
Communication Interfaces	Supports RS232 Interface and RS485 Interface
Baud Rate	RS485 default baud rate is 2400bps, RS232 default baud rate is 115200bps, supports 1200~460800bps
External Power Supply Interface	Provides one
Network
Network Protocol	TCP, supports connecting 4 TCP data servers TCP0~TCP3 simultaneously. Default TCP0 connects to "www.everiaction.com:9090" for data interaction with RS485.
Operating Frequency Bands	LTE FDD: Band 1,3,5,8LTE TDD: Band 34,39,40,41(2555Mhz~2655Mhz)GSM/GPRS: 900/1800MHz
Data Transmission	LTE FDD Rel.13: 10Mbps DL/5Mbps ULLTE TDD Rel.13: 8.2Mbps DL/3.4Mbps ULGPRS: 85.6kbps DL/85.6kbps UL(multi-slot class 12)
